Dual-Passband SAW Filter Based on a 32◦YX-LNSiO2SiC Multilayered Substrate

Paper Download

Dual-Passband SAW Filter Based on a 32° YX-LNSiO2SiC Multilayered Substrate.pdf

OMedaSemi  can provide 4-inch and 8-inch LNOI wafers and LN-SOI

 We provide 4-8 inch LNOI wafers (thin-film lithium niobate), which use surface activated bonding technology to bond thermal oxide wafers and X-lithium niobate crystal wafers together, and then control the thickness to the thickness you need through ion implantation, annealing, thinning or direct thinning and CMP polishing. It is worth noting that ion implantation and direct CMP and thinning have their own advantages and disadvantages. We provide customers with a variety of LNOI products. Also we are developing 6inch LTOI(lithium tantalate) wafer.

We also have a large stock available. You can visit this page to learn more：https://en.omedasemi.com/linbo3_on_insulator.html

Summary of the Article: "Dual-Passband SAW Filter Based on a 32° YX-LNSiO2SiC Multilayered Substrate"

This paper discusses the design of a dual-passband Surface Acoustic Wave (SAW) filter, leveraging a multilayered substrate structure. The filter is constructed using a 32° YX-LNSiO2SiC (Lithium Niobate-Silicon Oxide-Silicon Carbide) configuration, which significantly enhances the filter's performance.

Key highlights of the article:

1. Introduction of Multilayered Substrate: The study presents a novel SAW filter design using a multilayered substrate combining Lithium Niobate (LNS) and Silicon Oxide-Silicon Carbide (SiO2-SiC), offering distinct advantages in terms of filter performance, especially for dual-passband applications.

2. Theoretical Design: The paper outlines the theoretical principles behind the design of the SAW filter, including the selection of the 32° YX cut of Lithium Niobate. The choice of substrate ensures optimal propagation of surface acoustic waves with minimal loss and improved bandwidth.

3. Fabrication and Simulation: The article describes the fabrication process and the simulation results for the proposed filter. These results demonstrate the effectiveness of the dual-passband design, with good performance in terms of frequency response and overall filtering characteristics.

4. Performance Evaluation: The study compares the proposed SAW filter with existing models, highlighting its improved frequency selectivity and dual-passband response. This makes it particularly suitable for applications in communication systems that require high-frequency accuracy and reliability.

5. Conclusion and Future Work: The paper concludes by affirming the advantages of using the 32° YX-LNSiO2SiC multilayered substrate in SAW filter design. The authors suggest potential areas for future research, including the optimization of filter parameters for better performance and the exploration of other multilayered substrate configurations.
